Intelligent Flight Battery For DJI Mavic Air (1st Gen)– 2375 mAh / 27.43 Wh / ~21 Min Flight

Li‑Po Smart BMS, 11.55 V Nominal, 13.2 V Max Charge – For Mavic Air Only

Compatible Products

• DJI Mavic Air (1st Generation)

In The Box

• 1 × Mavic Air Intelligent Flight Battery

Product Overview

Rated at 2375 mAh (27.43 Wh) with 11.55 V nominal / 13.2 V max charge voltage (3S LiPo), it delivers up to ~21 minutes maximum hover flight time (lab: windless, 25°C, camera off, constant moderate speed). The onboard smart BMS communicates cell balance, temperature and remaining cycles to the DJI Go 4 app, and features over‑charge / over‑discharge protection plus auto‑storage discharge (~60 % after 10 days idle). Operate via a short‑press to check LEDs, long‑press 2 seconds to power on/off.

Key Features

️ ~21 Minute Max Flight Time

• Lab‑measured under ideal conditions; typical real‑world flight 16–18 minutes depending on wind, speed & camera activity.

Smart BMS

• Cell‑Level Monitoring: Real‑time voltage & health viewable in DJI Go 4 app.

• Over‑Charge / Over‑Discharge Protection: Auto cutoff to preserve pack life.

• Self‑Discharge Storage Mode: Auto‑drains to storage voltage after ~10 days unused.

Simple Power Toggle

• Short Press: LEDs illuminate to show remaining charge %.

• Long Press (2 Sec): Powers battery & connected drone on / off.

Charging

• Max Charge Voltage: 13.2 V

• Charging Temp Range: 5°C to 40°C (41°F to 104°F).

️ Technical Specifications

Usage Tips

• Check Charge: Short‑press button — 4 LEDs = full, 1 LED flashing = <25 %.

• Power On/Off: Long‑press 2 sec with battery installed in drone or standalone (standalone off‑mode only shows LEDs).

• Storage: If not flying > 3 days, allow auto storage discharge or use hub to manually trigger.

• Warm Batteries: In winter, bring cold packs to ≥ 15°C before charging/flying to avoid voltage sag.

• Transport: Use a LiPo‑safe pouch or hard case when transporting / shipping.

️ Important Notes

• 1st‑Gen Mavic Air ONLY: Not for Mavic Air 2 / Air 2 S / Air 3 or any other DJI drone — wrong voltage & connector will damage equipment and void warranty.

• LiPo Handling: Inspect for punctures, swelling or damaged contacts before each use. Do not use if swollen.

• No Deep Discharge: Land before first low‑battery warning; chronic over‑discharge permanently harms cells.

• Charging Safety: Charge on non‑flammable surface; never leave unattended during charge.
