Item Descriptions:
1. Turn on the dynamic navigation function, each time you receive the beacon of the rescuer, it will refresh the distance and orientation of the rescuer. When the search and rescue team is on the move, it will refresh the distance and position of the rescuer in real time.
2. Trekking, search and rescue, patrol, expedition, event support, helicopter aerial flight measurement and control. . Mountains, deserts, oceans, lakes, and air. . .
3. UV98 professional APRS dual-segment positioning handbench, using standard APRS digital coding, can directly work independently without third-party network and third-party software support, directly send and receive positioning data through radio U/V signals, widely used in outdoor sports, events Security, rescue and other occasions.

Host
Support U/V dual segment, A segment to send and receive positioning data, B segment voice call.
5W, full hand frequency, fast frequency adjustment
Support battery USB direct charging
Built-in temperature, air pressure, voltage and other auxiliary sensors
Support user independent firmware upgrade
APRS channel
APRS channel, voice channel arbitrarily set, A/B channel APRS, A/B channel voice
Support CH A to receive CH A transmission, CH A to receive CH B transmission (differential rotation), CH A to receive, A to send + B to send
Support CH B to receive CH B, CH B to receive CH A (differential), CH B to receive, A to send + B
Support off-network use, no network, direct mutual positioning

interface
1.8-inch color display, Chinese and English menu
Support advanced GPS interface, beacon list interface, real-time beacon interface, beacon record analysis interface
APRS Track
Support fixed station FIXED, sports SPORT, 2 site modes
Support complete TRACK tracker, support intelligent, timing, PTT linkage, queue beacon
Support beacon additional information, mileage, satellite number, voltage, temperature, air pressure, etc.
Support mileage calculation, support accumulated mileage or automatically clear 0
Support for automatic icons (TRACK smart mode)

Bluetooth
Built-in latest 2.0+4.0 dual-mode Bluetooth, compatible with Android, Apple
Support Bluetooth output KISS hex, UI, GPWPL, KISS ASC, GS232B and other protocols
Support Bluetooth output GPS data (GPRMC+GPGGA), support mixed output
Support Bluetooth KISS data bidirectional transparent transmission
Support streaming cloud, APRSdroid, LOCUS, Ovi and other APP
Support wireless Bluetooth setting parameters

APRS relay
Support full DIGI relay function, support custom relay name
Support relay channel A\B arbitrary forwarding
Support relay remote turn-off function

GPS/Beidou
Built-in high-performance GPS\Beidou\GLONASS multi-mode hybrid positioning engine
APRS algorithm
Built-in advanced CMX hardware programming algorithm
Built-in 8-level digital level adjuster (both transmitting and receiving)
data analysis
Built-in large-capacity data storage, 100 beacon storage, viewing, intelligent sorting
Built-in advanced algorithm to support rich data analysis
Support heading, north position, relative motion position calculation
Support Maidenhead grid positioning system
Supports trigonometric calculations such as APRS distance, horizontal angle, and elevation angle
Support automatic tracking control of G5500 aircraft, ships, etc.
Remotely
Remote control peripheral module sensor input and relay telemetry control module
software
Companion PC setup software (Chinese, English) (requires .NET 4.0)
Professional APRS dual stage console!
The handset itself has dual-mode Bluetooth built-in. The optional external Bluetooth can be plugged into the PC and can be used with the handset’s built-in Bluetooth, wireless connection, wireless settings or PC communication.

Updated 20190212C firmware version, support dynamic navigation
When the dynamic navigation function is enabled, each time a beacon for help is received, the distance and direction to the helper will be refreshed once.
When the search and rescue team is marching, it will refresh the distance and position with the person asking for help in real time
Hiking, search and rescue, patrol, adventure, event support, helicopter aerial flight measurement and control. .
Mountain, desert, ocean, lake, aerial. . .

common problem:
Q: How far is this handstand?
Answer: Urban environment 1-3KM, open area lake 1-8KM, standing on the space station, the whole of China
Q: Can it communicate with other brands of hand or car platforms?
Answer: 1. As long as the frequency is the same, the voice can communicate in a certain range.
2.The positioning should be the same with APRS function.
Q: Is it waterproof?
Answer: It is simple and waterproof, and can not be thrown into the water.
Q: Are there any advanced waterproof machines?
Answer: Yes, prepare a purse, import YAESU 2DR and the like
Q: How much power?
Answer: 5W
Q: Which mobile APPs are supported by the UV98 handset?
Answer: Android Liuyun, Aowei, LOCUS MAP, APRSdroid, etc.
Apple, no software support, Apple Ovie can try

Packages Included:
1 x Walkie Talkie
1 x High-Gain Antenna
1 x AD Adapter
1 x Belt Clip
1 x User Manual
