Input Frequency

1).Low Band:10.70 GHz -11.70GHz

2).High Band:11.70 GHz -12.75GH

Output Frequency

1).Low Band:950-1950MHz

2).High Band:1100-2150MHz

L.O. Frequency

1).Low Band:9.75GHz(1MHz@25°C)

2).High Band:10.6 GHz(1MHz@25°C)

L.O. Stability

1).Low Band:±1MHz(-40°Cto+70°C)

2).High Band:±1MHz(-40°Cto+70°C)

Noise Figure

0.1dB

Conversion Gain

70dB

Gain Flatness

≤+/-2dB

Intput VSWR

2.5:1(max)

Output VSWR

2.0:1(max)

Output Connector

F-female Connector

Output Impedance

75Ω

Cross Polar Isolation

20dB(min)

Supply Voltage

1)Ca:11.5-14.0v(Vertical Polarization) 13VDCType
2)Cb:16.0-19.0v(Horizontal Polarization)18VDCType

Direct Current

150mA

Control Signals

1).Low Band:Ca or Cb(see below) 2).High Band:Cc or Cb(see below)

3)Cc:continues 22KHz

Operating Temperature

-40°Cto+70°C

Storage Temperature

-40°Cto+80°C

Relative Humidity

0%-95%

Phase Noise

1)-50dBc/Hz@1kHz(max)

2) -75dBc/Hz@10kHz(max)
3) -95dBc/Hz@100kHz(max)

Image Rejection

45 dB (min)
